New Bachmann Class 40 Sound Fitting Guide
The Bachmann class 40 comes with two built in sugarcube speakers making it very easy to fit sound to, but you may want to upgrade those to something better. Here's how we did ours. Start by removing the 8 screws that hold the body. Theres 2 under each nose, and 4 more central ones. Once the body is off you'll see the 2 speakers. To remove them, unscrew the PCB and remove the screws that hold the speakers from underneath it. You'll be left with a flat space, with some brass pads which can be soldered to. We used...
Bachmann Class 70 DCC Sound Fitting Video
I have made a video, explaining how to remove the body and fit sound to this model. Find the sound decoder here Find the speaker on it's own here
Bachmann Class 47 And 57 Sound Fitting Guide
Start by removing the 6 body screws, there are 8 screws on some class 57's with delner couplings on the cab ends. Once the screws are removed, the cab door glazing is still clipped to the chassis, use a prising tool to release the clips without the windows falling out. once inside you'll find plenty of space for a pair of 20x20x7 megabass speakers. These fit with no modifications, and they fit under the fans, theres no need to remove them. Find the decoder and speakers here: Class 47/0, Class 47/4 (and all ETH versions), Class 57
Sound Fitting The 21 or 8 Pin Bachmann Class 20
These are amongst the easiest models to sound fit, theres slightly more space in the 21 pin model than the 8 pin one. Start by removing one screw from each end to remove the body For the 21 pin model we recommend the slimmest double iPhone speaker For the 8 pin model we recommend the 26x11x7 speaker Find the decoders and speakers here.
Sound Fitting The Latest 21 Pin Class 33 'Slim Jim'
Quite a few people have already asked if my other class 33 fitting guide applies to the 'slim Jim' version, I wasn't sure so I ordered one to try. Start by prising off the body, its a very tight fit, and doesn't come off as easily as other class 33 models Its largely the same as fitting sound to the other class 33 models, but the model is now 21 pin. Theres space for a speaker on top of the pcb, it doesn't have to sit right at the end like it does on the recent 8 pin ones. There would also...
